Heidolph Hei-VAC Diaphragm Vacuum Pump
Ultimate Vacuum
2 mbar
Suction Capacity
1.3 m³/h
Stages
2 Stages
Features
- Constructed with chemically resistant fluoropolymer for media contact components
- Durable PTFE design ensures superior diaphragm lifespan
- Metal core in head cover and clamping disc for long-term performance
- Direct pump drive design (no belt) for quiet, low-vibration operation
- Optimized gas ballast valve prevents condensate buildup in the pump
- Two-stage diaphragm pump with maximum pumping speed of 1.3 m³/h
- Achieves an ultimate vacuum of 2 mbar for high-efficiency performance
- Compact design with dimensions of 326 x 143 x 175 mm and weight of 7.1 kg
All components that come in contact with media are made from chemically resistant fluoropolymer. The durable PTFE design guarantees a superior diaphragm lifespan. Head cover and clamping disc have a stable core made from metal that offers unsurpassed long-term performance. The direct pump drive (without belt) has no wear parts, is exceptionally quiet and creates a very low vibration environment. The physically optimized gas ballast valve prevents from condensate collecting in the pump.
Condenser is not in scope of delivery.
INCLUDED:
The Heidolph Hei-VAC Diaphragm Vacuum Pump includes:
- Power Cord
- Operator’s Guide
- Full 3 Year Manufacturer’s Warranty
Heidolph Hei-VAC Diaphragm Vacuum Pump Specifications
|
Diaphragmpump |
Two-stage |
|
Maximum Pumping Speed |
1.3 m³/h |
|
Ultimatevacuum |
2 mbar |
|
Combinablewith a condenser |
No |
|
Power input |
80 W |
|
Weight |
7.1 kg |
|
Dimensionswithout condenser (w/d/h) |
326 x 143 x 175 mm |
